RS-6 Randomizer Automated Scraping Floor Machine

Width capacity: 3” – 6”

Thickness capacity: .375”  – 3.00”

Automates the production of authentic looking antique wood scraped flooring

Creates hundreds of patterns that can be saved and used over again as needed

Can provide various radial, flat type scrapes, smooth and chatter cutting and jumping knives to create divots where the knife enters and exits the surface of the wood

Edge scrapers can provide chamfered and pillow type edge work

Thru-feed type machine – cardan shaft

Variable feed speeds

(2) Motorized denibbing stations

8” wide x 8” diameter wire brush type head (each)

Dust hood (each)

2HP, 230/460v, 3PH motor (each)

(5) Steel driven table feed rollers

(1) Steel idler table feed roll

(8) Tiltable programmable Servo controlled axis scraping tool heads

Top pneumatic rubber feed wheels over each table roller

Non-repeating scraping patterns

(1) Manual station

Feed beam and tool actuators all move together

Programmable knives can oscillate side-to-side and jump up and down

Siemens Simatic HM1 colored touch screen controller with memory setting

Sound safety enclosure with (3) lift up access hoods with large viewing windows

Dust manifold

Free-standing outfeed roll feeder

(1) Driven table roller

6½” wide

(3) Idler table rollers

(1) Top spring-loaded holddown gravity roller

½HP, 115/230v, 1PH motor

Incline slide table

8’ long x 4’ deep

(2) Sections of gravity roller conveyor

14½” wide x 7’ long (each)
